EV charger liquid-cooling module pump P6216
Published:2018-09-06
Remarks: - We can offer OEM/ODM service. - If you are interested in our products,pls send your requirements to sp005@dgshenpeng.com - Our Facebook is：Shenpeng Pump |
■ Product application
- Heating vertilation air conditioning
- New energy automotive cooling circuit
■ Product information
- Ambient temperature:-40 to 125℃
- Medium temperature:-40 to 120℃
- Medium:Clear water,antifreeze
- Weight:0.65Kg
- Protection level:IP67
- Insulation level:H
- Service life:20000 hours
- Inlet and outlet:22mm
■ Curve
Rated Voltage | Voltage Range | Rated Current | Max Head | Max Flow | Rated Poweer | Max Noise |
V | V | A | m | L/min | W | dB（A） |
| 12 | 8-20 | 6 | 15 | 43 | 72 | ≤45 |
●How long is your delivery time?
- Sample order is 7~10 days.
- Bulk order is 15~20 days.
- If there is pumps in stock, it is 2 days.
●How long is your warranty of pump?
-Warranty is 2 years, can be repaired or returned free of charge if non-man-made damage.
●What’s the payment method?
- Paypal or T/T，L/C .
●What certificates have your pumps passed?
- All our products have passed CE, RoHS, Reach.
- Some pumps met FDA, UL.
■ Specifications
Type | P6216 |
Rated Voltage | 12V |
Voltage Range | 8-20V |
Max Flow | 43L/min |
Max Lift | 15m |
Max Noise | 45dB |
Motor Type | DC Brushless Motor |
Food Grade(Y/N) | N |
Liquid Temperature | -40-120℃ |
Ambient Temperature | -40-125℃ |
Pump Theory | Centrifugal Pump |
Medium | Water, antifreeze |
Protection Level | IP67 |
Using Place | Vehicle |
Power Consumption | 72W |
Service Life | 20000 hours |
OD of inlet | ∅22mm |
OD of Outlet | ∅22mm |
Power supply | Battery / Electric / Solar panel |
Structure | Single-stage |
Material | PPS |
Customized functions | 1, Dry-running protection 2, PWM speed adjustable 3, FG signal output 4, Locked-rotor protection |
Remarks | Not self-priming |
