220V chiller circulating water pump P7505
Volt: AC220V
Head: 15m+
Noise: ≤55dB(A)
Speed control ways:
Protection level:
Function:
Medium temperature:
Remarks: - We can offer OEM/ODM service. - If you are interested in our products,pls send your requirements to sp005@dgshenpeng.com - Our Facebook is：Shenpeng Pump |
■Product application
Large and medium-sized laser chiller
LED cooling, semiconductor cooling
Cooling cycle of laser machine, cutting machine and engraving machine
Other equipment requiring pressurization cycle
■Product information
Ambient temperature:-5 to 55℃
Medium temperature:0 to 55℃
Medium:clear water
Using place:Indoor
Weight:1.5kg
Insulation level:F
Service life:20000 hours
■ FAQ
●How long is your delivery time?
Sample order is 7~10 days.
Bulk order is 30~35 days.
If there is pumps in stock, it is 2 days.
●How long is your warranty of pump?
Warranty is 2 years, can be repaired or returned free of charge if non-man-made damage.
●What’s the payment method?
Paypal or T/T，L/C .
●What certificates have your pumps passed?
All our products have passed CE, RoHS, Reach.
Some pumps met FDA, UL.
■ Specifications
Type | P7505 |
Rated Voltage | AC220V |
Voltage Range | AV190V - 260V |
Max Flow | 60L/min |
Max Lift | 30m |
Max Noise | 55dB |
Motor Type | AC Brushless Motor |
Food Grade(Y/N) | N |
Liquid Temperature | 0 to 55℃ |
Ambient Temperature | -5 to 55℃ |
Pump Theory | Centrifugal Pump |
Medium | Hot or cold water |
Using Place | Indoor |
Power Consumption | 260W |
Service Life | 20000 hours |
Power supply | Battery / Electric |
Material | PPS+40%GF |
Customized functions | 1, Dry-running protection 2, Forward and reverse rotation function |
Remarks | Not self-priming |
■Curve
Rated Voltage | Voltage Range | Max Head | Max Flow | Rated Poweer | Max Noise |
V | V | m | L/min | W | dB（A） |
AC220 | AC190-260 | 30 | 60 | 260 | ≤55 |
